BLUETTI D40 DC-DC Battery Charger

FAQS

• Q1: What is the difference between the AC200L and AC200MAX?

  A:

  1. Output power: 2,400W for AC200L, while 2,200W for AC200MAX.
  2. Max. Input: 2,400W (AC + DC / Solar) for AC200L, while 1,400W (AC + PV) for AC200MAX.
  3. AC200L has lower noise level ≤50dB .
  4. AC200L requires no external charging adapter for AC charging.
  5. App Control: AC200L supports Bluetooth and WiFi, while AC200MAX only supports Bluetooth.

• Q2: How many expansion batteries can I connect with the AC200L?

  A:

  AC200L + 2*B210 = 6,348Wh;
  AC200L + 1* B230 = 4,096Wh;
  AC200L + 2* B300 = 8,192Wh.

• Q3: Can I connect third-party expansion batteries to AC200L?

  A:

  No.

• Q4: Does AC200L support App control?

  A:

  Yes. Once connected via Bluetooth or WiFi, the BLUETTI App enables you to control the AC200L remotely, like switching the working mode and upgrading the firmware.

• Q5: Can I use AC200L as a UPS?

  A:

  Yes. Within 20ms switching time.

• Q6: What kind of solar panels should I choose for AC200L?

  A:

  Open Circuit Voltage: 12-145V
  Input Power: 1,200W Max.
  Include MC4 connectors.
  Highly Recommended:
  6x BLUETTI PV120: ≈3.5hrs.
  5x BLUETTI PV200: ≈2.5hrs.
  3x BLUETTI PV350: ≈2.5hrs
  * For reference ONLY.

• Q7: Can I connect two units of AC200L together for more power (240V Split Phase Bonding)?

  A:

  No.

• Q8: Is the AC200L power station waterproof?

  A:

  No. So please do NOT store it in a humid environment for a long time for optimal performance.

• Q9: Can it charge and discharge at the same time?

  A:

  Yes. It supports pass-through charging.

• Q10: Can I charge or discharge AC200L in sub-zero temperatures?

  A:

  You can charge the AC200L to power your devices in cold weather, but avoid recharging it below freezing. The temperature ranges for AC200L are:
  Charge: 0-40℃ (32-104℉);
  Discharge: -20-40℃ (-4-104℉);

• Q11: What appliances can AC200L work well with?

  Add up the total wattage of your devices and ensure it doesn't exceed AC200L’s rated 2,400W.

• Q12: How long can it run my device?

  Running time = Battery capacity × DoD × η ÷ Device rated power
  DoD refers to Depth of Discharge and η is local inverter efficiency. For AC200L, DoD and η are 95% and 93%. If you run a 1,000W microwave oven with it, the running time will be:
  2,048Wh × 95% × 93% ÷ 1,000W ≈ 1.81hrs
  Note:
  1) The formula is NOT suitable for inductive loads with compressors, like refrigerator, air conditioner, etc.
  2) The above data is for reference ONLY.

• Q13: What is the maximum input of the BLUETTI AC200L?

  2,400W via AC outlet and solar panels simultaneously.

• Q14: Can I lay on its side to save space?

  No. this may damage the internal structure. Please keep it upright during storage or moving.

• Q15: Can I hot-swap expansion batteries to AC200L?

  Yes.

• Q16: Is it possible to replace the built-in battery?

  No. If the battery pack is faulty or even dead, please contact BLUETTI Support for further assistance.
